| Description | |
| Model: | 2m³ Concrete Mixer Three Wheeler Vehicle |
| Engine | |
| Type | Diesel |
| Max. Engine Output (HP) | 32 HP |
| Emission: | China 3 |
| Gear Box | Fourth gear with high and low speed |
| Body | |
| Overall Dimensions (LxWxH) mm: | 4700x1630x2500mm |
| Capacity | 2m³ |
| Brake Systerm | Barely able to brake |
| Suspension | Extral Heavy |
| Wheel Base | 1800mm |
| Number of axles | 2 |
| Number of wheels | 3 |
| Turning Systerm | Hydraulic directional booster |
| Max speed km/h | 50 |
| Mixer | |
| Material of tank | High Quality Alloy Steel |
| Water Tanker | 200L |
| Feeding speed(m³/min) | 2 |
| Discharge speed(m³/min) | 2 |
| Residual ratio(%) | <0.5 |
| Scope of discharging | 180° up and down |
| Cooling system | High efficiency hydraulic oil cooling system /16L |
| Head material | 8mm Double head alloy steel |
| Leaf blade material | JJ520 High Quality Alloy Steel |
| Reduction box | HY-61-2-C |
| Hydraulic system | BMS-125 |
Company Introduction:
Zhengzhou Dongfeng Mid-south Enterprise Co., Ltd is the second subsidiary company of Dongdfeng Group, which was established in 1969. We are manufacture and exporter of Dongfeng Special Purpose Vehicle Series:
. Concrete Mixer Trucks, Suction Sewage Trucks, Sweeper Trucks, Fuel Tanker, Water Tanker, Refrigerated Trucks, High Platform Truck, Garbage Trucks, Fire Fighting Trucks, Truck Crane and So on.
Commercial Vehicle
Dump Truck Series:
6×4, 8×4 ---Heavy duty tipper Dongfeng T-Lift with loading capacity 20 to 55Ton,
6×4, 4×2--- Medium duty tipper Donfeng Kingrun with loading capacity 15 to 20Ton,
4×2--- Light duty tipper truck Dongfeng Rituo with loading capacity from 3Ton to 14Ton.
Tractor Truck Series: 4×2,6×4 Dongfeng Kingland Tractor Head Special suit for middle and long distance transport.
Cargo Box Truck:
Dolica 4x2 ---light cargo truck with capacity from 2 to 10 ton,
Captain 4x2 ---high end light cargo truck with capacity from 2-10 ton,
Kingrun 4x2 ---Medium duty cargo truck with capacity from 13-20 ton,
Kingland 6x2, 6x4 and 8x4 ---Heavy duty cargo truck with capacity from 20-40 ton.
Motor Vehicle Spare Parts: Series Auto Parts of Series Vehicle and Machinery, like filter, PTO, hydraulic pump and so on.
Construction Machinery: Concrete mixer, Concrete Batching Plant, Road Roller, Wheel Loader, Excavator, Forklift, Crane and So On.
Farm Machinery and Farm Machinery parts:
Wheel and Crawler Farm Tractor from 11 Hp to 220Hp, Planter, Harvest Machinery and Farm Implement and So on.
FAQ:
Q1. What is your terms of payment?
A: 40% prepaid as deposit by T/T, the balance of 60% should be cleared before delivery.
Q2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF...
Q3. How about your delivery time?
A: Generally, it will takes 7 days after receiving your payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q5: How do you make our business long-term and good relationship?
A1. We keep good quality and competitive price to ensure our customers benefit ;
A2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
